Flat Sheets
Available Flat Sheet Sizes
- **Available in lengths up to 10'**
- Widths: 40.875", 43" and 48"
Colors
- All Silicone Modified Polyester Paint Finishes
- All Kynar Finishes
- Galvalume Plus
- 16 Oz Copper (3' x 10')
Gauges
- 29ga (40.875")
- 26ga (43" and 48")
- 24ga (48")
Packaging
- Available in rolls
- Price based on quantity
Fasteners
1/4" Wood Grip Screw
- Application: Metal to Wood
- Head Size: 1/4" Hex Head Screw
- Available Sizes: 1", 1 1/2", 2", 2 1/2"
- Quantities Sold: 250/ Bag
5/16" Wood ZAC Screw
- Application: Metal to Wood
- Head Size: 5/16" Hex Head Screw
- Available Sizes: 1", 1 1/2", 2", 2 1/2"
- Quantities Sold: 250/ Bag
*WARRANTY AVAILABLE
Learn more about the technical advantages of ZAC Screws
Pancake Head Wood Screw
- Application: Metal to Wood (Standing Seem)
- Head Size: Square Head
- Available Sizes: 1" Only Available
- Quantities Sold: 250/ Bag
5/16" ZAC Metal Screw
- Application: Metal to Metal
- Head Size: 5/16" Hex Head Screw
- Available Sizes: 1", 1 1/4"
- Quantities Sold: 250/ Bag
*WARRANTY AVAILABLE
Learn more about the technical advantages of ZAC Screws
Pancake Head Metal Screw
- Application: Standing Seem Panel Over Metal Purlin
- Head Size: Square Head or Phillips
- Available Sizes: 1" Only Available
- Quantities Sold: 250/ Bag
5/16" ZAC Metal Lap
- Application: PBR Panel Leg Lap
- Head Size: 5/16" Hex Head Screw
- Available Sizes: 7/8"
- Quantities Sold: 250/ Bag
*WARRANTY AVAILABLE
Click here to learn about the advantages of ZAC Screws
Do your screws have a warranty?
On exposed fastener systems the quality of the roof is only as good as your screws. Our screws are so good that we offer a lifetime warranty that stands behind them. This is due to ZAC's peak performance from the texture of the paint to the hi-lo thread that prevents screws from backing out years later. The over-sized umbrella head keeps the gasket washer from being exposed to the elements. Once the ZAC screw is appropriately fastened, the gasket bonds to the roof panel giving a weather tight seal. The paint system used on the ZAC has a zinc alloy cap that prevents the screw from rusting. Don't leave your roof with thousands of holes unless you have a top of the line screw that will last as long as your roof. For more information check out the ZAC Warranties below.
Boots and Rivets
Pop Rivets
- Material rivet mandrel: A = Aluminum
- Material rivet body: T = Carbon steel
- Typical Applications: Joining Metal in side laps and flashing applications with high grip.
Pipe Boots
Regular Boots: Available for flashing exposed pipes. Made to cover sizes 3/4" to 19" pipes
Retro Flashers: These are made to flash around pipes with electrical wires that can be zipped on low side of the roof slope for appropriate flashing.
High Temperature Boots: These are rated to 450 degrees to help cover exposed high temperature pipes on your roof system.
*All Flashers have a moldable foot that can be caulked and placed over almost any roof structure.*
Closures
Ridge/Hip Closures
Help keep water, leaves, and bugs out of your ridge by using closures. Closures are very essential to the roof system and are the most common item forgotten by roofing contractors.
Here are our items available for each panel:
PBR Closure
3ft Wide
Rib Panel Closure
3ft Wide
5V Closure
2ft Wide
*Available in both inside (under the panel) and outside (on top of the panel).*
Vented Closure
2" x 10ft / rolls (2 rolls / package)
Need added ventilation to help keep your roof cool? The Hip and Ridge vent helps keeps air flow across your roof system adding better energy efficiency to your home.
Sealants and Tape
Novaflex Metal Roof System
- Excellent adhesion and flexibility -Mildew Resistant
- Extrudes down to -20°F - Freeze thaw stable
- Service Temperature -40° to +400°F
- Application Temperature 0°F to +120°F - Tack free in 10 minutes
- Completely cured in up to 2 days
- Adheres to: Wood, Metal Siding, Galvanized Steel, Flashing, Metal Roof, Galvanized Gutters, Trim, PVC, Aluminum, Masonry, Downspouts, Roof Tile
- Adheres to: Kynar
- Meets CARB and OTC Regulations (VOC Compliant)
- Novaflex Metal Roof Sealant provides unbeatable adhesion to metal, coated metals, wood, masonry, PVC and most common construction materials.
*Available in color to match panel specific colors*
Butyl Tape
- 3/32" × 3/8" × 20 yards
- Sealant lap / flashing sealing
- Superior lap sealing properties
- Tremendous workability and adhesion
- Can be shear-cut
- Low flame-spread
- Solvent-free, no shrinkage or slump
- White, not completely waterproof
- Maintains peel adhesion over time
Insulation
R+HEATSHIELD Radiant Barrier Foil
Benefits of Radiant Barrier Foil Insulation
- Cuts energy consumption and costs
- Improves interior comfort
- An economical radiant barrier attic insulation
- Effective means of temperature control in a wide variety of applications
- Solid version qualifies as an air and moisture barrier
- Superior tear and puncture resistance
- Can span eight feet unsupported
- Environmentally safe and non-toxic
- Lightweight; easy and safe to install
Technical Information
- Reflectivity ASTM E408: 94 percent
- Emissivity ASTM E408: 6 percent
- Flame & Smoke Rating: 5/20
- Weight: 14 lbs./500 sqft.
- Thickness: 4.0 mil
AYR-FOIL R-Foil Foil
Benefits of R-Foil Insulation:
- Blocks 97% of Radiant Heat Transfer
- Prevents Interior Condensation
- Class 1/ Class A Fire Rated (ASTM E84-08)
- Puncture and Tear Resistant
- Unaffected by Humidity
- Will not Promote mold and mildew
- Safe, non-toxic and non-carcinogenic
- Easy to Handle and Install
- UV-Resistant
- Comes in rolls of 500 sqft (4ft x 125ft)
- Tested added R-Value of 10 on 45° Pitch Roof
